KC601 Pro
Quad HDMI video switcher with 5.5" LCD Screen HDMI video record function, suitable for live broadcast and streaming
FoMaKo live stream video switcher panel is the world's first 5.5-inch 10 display monitor with multi-layer video processing, YUY2 Lossless UVC streaming, VENC hard-encoding record, professional sound card-level audio processing, 4cameras live broadcasting production, highly integrated and compact audio and video live stream with broadcast-level live production by 4 x camera PTZ control simultaneously. Only by 29 buttons, 3 knobs and T-Bar can operator use the M/E panel to realize single-person live broadcasting friendly and easily.
Share:
Tags:
Product introductionTech SpecPackagingDownload

Accelerate Live Production
Production is easier and fun with FoMaKo video switcher panel

FoMaKo video switcher panel is a very advanced video switcher, it contains a number of new technologies and functions: 4 x HDMI signal source, 2 x background pictures can realize three layers and layers switch, 4 chroma keys and 2 luma keys are ideal for high-end production and virtual scenes.

You can connect to various video sources such as cameras, TV, play boxes, PowerPoint and animations etc.. Through powerful Chroma Key, various creative transitions, image pools, downstream KEY, audio mixer, multi-view and other functions, operator can create exciting live productions.

FoMaKo live streaming switcher can bring you wonderful multi-camera live production! Designed with professional Preview and Program switching via TBAR, operator will enjoy the style of self-directed and self-acted video production. By zoom, crop and layer move freely, can be realized pixel-level layer editing, with a highly flexible layer layout and mix engine.

   FoMaKo video switcher panel unique operation design, by using the panel to control the option, the operator can connect the 4 inputs as you like. The PTZ camera control signal is used to load and save preset points, and it is very convenient to simulate different movement of 4 x cameras.

Edit and preset the scenes according to different applications, by the powerful functions and excellent operation panel to make your video live production more fun and easier.

● Easy to carry with mini size
●1080p 60fps USB high bit rate recording
● Friendly audio button selection, 8-channels mixing, 5-band EQ, XLR

● Easy to monitor and preview with 5.5” wide gamut FHD LCD
● Quad HDMI inputs, Dual HDMI outputs for PGM, One UVC streaming
● Dual audio inputs, support both Line-in and mic
● One audio output, with selectable sources
● T-bar switching, more than 30 effects, supports custom effects
●  Four Power Chroma Keys & Two Luma Keys

● Inner media library, supports user defined pictures and imported pictures
● Logo with alpha channel, supports PNG format
● Flexible layers switching, each with position, size , chroma key and mask
● FTB and image freezing
● supports 4 PTZ Cameras control
● Agilely control with web on PCs and phones, without additional installation.












Video
InputHDMI Type A x 4 (INPUT 1 ~ 4)
Output (PGM)HDMI Type A x 1 (PGM OUT)
Output (MVR)HDMI Type A x 1 (MULTI-VIEW OUT)
Streaming OutputUSB3.0 Type A x 1
Recording OutputUSB2.0 Type A x 1
Audio
InputCombo type (XLR, 1/4-inch TRS phone) x 2, balanced,
phantom power (DC 48 V, 10 mA Max)
3.5mm TRS phone type x 2, Mic In / Line In Supported
Output3.5mm TRS phone type x 2, Phones / Line Out
Communication
RJ4510/100/1000 BaseT x 1, Upgrade / PTZ Control / Remote Control
USB Type-CUSB Type-C x 1, Upgrade / Picture Import
Power
DC Power JackPower Socket, Ф5.5 x 2.1mm
USB Type-CUSB Type-C x 1, Locking Screw, USB Power Delivery (PD 3.0)
Performance
Input ResolutionHDMI:Up to 1920 x 1080p60
Output ResolutionHDMI:Up to 1920 x 1080p60
Supported StandardsHDMI:1.3
USB:3.0
H.264:ITU-T H.264 | ISO/IEC 14496-10 AVC
Supported ProtocolPTZ:VISCA Over IP
UVC & UAC:UVC 1.0 & UAC 1.0
VideoVideo Formats:HDMI 1.3 | HDCP 1.4
Video Sampling:YUV 4:4:4 (HDMI)
Color Space:YUY2 (USB3.0)
Video Latency:4 frames
AudioLine In Delay:up to 8 frames
Audio Formats:HDMI:Linear PCM, 24 bits/48 KHz, 2 ch
USB:Linear PCM, 16 bits/48 KHz, 2 ch
Record/StorageDisk Formats:FAT32(≤32 GB) | NTFS(64GB~2T)
Recording Formats:MP4
Power Requirements
Input VoltageDC 12V/2A (via Power Socket or USB-C PD3.0 supplied)
Max Power20W
CompatabilityUSB Type-C x 1, Locking Plug, USB Power Delivery (PD 3.0)
Supported CablesCertified USB PD Aware
Operational Environment
Temperature0~60
Humidity10%~85%
Physical Specifications
WeightDevice:1.14kg
Packaged:1.835kg
DimensionsDevice:Panel:230mm×144mm;
Side:topline 45.6mm, baseline 22.4mm;
Packaged:280mm×180mm×130mm
